Specifications
Item
Spec
Inputs
Point clouds (LAS/E57/RCP), design (IFC/DWG)
Checks
Surface/element deviations, sections, key dims
Tolerances
Project-defined (e.g., ±10 mm, ±20 mm)
Outputs
Heatmaps, pass/fail tables, snapshots
Formats
PDF pack, CSV issue list, DWG/IFC refs
Method
Deliverables
QA PASS
Quality Checks
- Alignment notes (CRS / grid / levels)
- Control & checkpoints summary
- Thresholds used by element/area
| Alignment residual | 6 mm (≤ 10 mm) |
|---|---|
| Pass rate | 96% within tolerance |
| Issues flagged | 8 |
| Snapshots | 24 |
